Engine Type |
4 Stroke, Air Cooled, Single Cylinder SI Engine |
Displacement |
199.26cc |
Maximum Power |
7.5 kw @ 4750 rpm |
Maximum Torque |
15 Nm @ 3000 rpm |
Bore x Stroke |
62 mm x 66 mm |
Maximum speed |
60 ± 2 km/h |
Engine idling rpm |
1250 ± 100 rpm |
Idle CO |
<1.5% @ Tail Pipe |
Air Filter Type |
Cylindrical- Paper filter with dry foam |
Starting System |
Electric, i-Touch Start & Hand Start |
Max Gradeability |
100 Degree |
Gear |
Manual, 4 Forward & 1 Reverse |
Clutch Wet |
Wet, Multi plate type |
Differential |
Integral with Engine |
Frame |
Semi Monocoque chassis Pressed longitudinal & cross members |
Overall Length |
2647 mm |
Overall Width |
1329 mm |
Overall Height |
1740 mm |
Ground Clearance |
165 mm |
Wheel Base |
1990 mm |
Rear Wheel Track |
1150 mm |
Kerb Weight with 90% Fuel |
347 kg |
Maximum GVW |
677 kg |
Size Front / Rear |
4.00-8, 76E 6PR |
Tyre pressure Front (laden) |
30 psi / 2.11 kg/cm² |
Tyre pressure Rear (laden) |
34 psi / 2.40 kg/cm² |
